3.3. CONNECTING THE MODULE WIRING
Before performing any
work on the module, make
sure that the pump and
module electricity supply
has been switched off and
that it cannot be
Press two top hooks on the display panel
(Use flat tip screwdriver if needed) and
simultaneously pull display panel away
from the pump.
Disconnect display panel cable to ease
access to the module wiring.
Wiring can now be connected.
