IMP PUMPS NMT Max C - Page 13

14
Relay and Ethernet connection
2
1
3
4
5
6
7
8
9
0
NC
C
NO
RELAY ANALOG
A/D+
SET2 SET3 SET1
+24 V
0V
B/D-
0V
RS 485
ETHERNET
LED2 LED1
MODE
2
1
3
4
5
6
7
8
9
0
SET3/ FB
SET2 / MAX
COM / 0V
SET1 / RUN
A/D +
B/D -
NC
C
NO
LED2 / ACT
LED1 / LINK
ETHERNET
MODE
NOTE: To maintain pump IP protection, the network cable should be pulled through the gland inlet and then
crimped to a connector.
