NanoPhotometer
®
P-Class User Manual
Version 2.1 Page 45 / 70
Add Peak (Shortcut button 5)
Graph Scale (Shortcut button 6)
Add Peak (Shortcut button 5)
Adds a user defined peak at the current cursor position. The entry
is then displayed in inverse colouring to discriminate between
user defined peaks and auto-detect peaks. When the cursor is
positioned over the user defined peak a legend “User Defined
Peak” appears at the top of the graph. The option then changes to
Delete Peak to enable the user to remove the peak.
Graph Scale (Shortcut button 6)
This enables the user to set up a defined graph by defining the
limits in either or both of the x and y axes.
Zoom mode:
This sets up the operation of the Zoom keys (up and down
arrows). The “x & y axis” expands the display around the cursor
measurement point, whilst the other options select the
absorbance or wavelength axes respectively. With x or y axis limits
set to on, zooming out will only be permitted to the set limits.
x/y axis limits:
Setting “x (or y) axis limits” to “On” activates the start and finish
points of the desired graph to user defined specific wavelengths
and/or absorbance values.
Pressing Cancel
