NanoPhotometer
®
P-Class User Manual
Version 2.1 Page 59 / 70
Direct Data-output to PC:
Connection between NanoPhotometer
®
P-Class and PC is possible with a USB cable connection:
Select how the data are send. Options are Computer (USB) or None. Press OK
to store the settings and return to the Utilities folder OR press Cancel to
return to the Utilities folder without storing the settings.
If Computer (USB) is selected all measured data are sent automatically to the
PC. The file is closed and saved once the method is left by pressing Cancel
or parameters are changed in the parameter settings.
7.3.3 Loading / changing the printer paper
1. Lift off the cover 3. Paper gripped
2. Feed in the paper 4. Cover replaced
Normally the paper is automatically gripped.
Sometimes it helps if
the platen lock is
released
Lock the platen
and turn the wheel
to feed the paper.
