Start-up

IMT Analytics AG

5.3.7 ±1 bar pressure sensor (PF-301 VAC)

With FlowAnalyser PF-301 VAC there is an additional ± 1 bar sensor that is connect-

ed to the designated port. The connecting nipple is marked with a yellow ring.

±1 bar pressure sensor

Measuring range: -1000 – 1000 mbar

Accuracy: ± 0.5% of reading or 2 mbar

With the ± 1 bar pressure sensor variant a port of the differential

pressure sensor (± 150 mbar) is connected to the remaining con-

nector and the second one is connected to the environment. The

measuring range remains the same.
