In Phase IPS 247BT - Advanced Bluetooth Settings and System Reset; Bluetooth Device Management and Reset; Technical Specifications; System Specifications Overview

12
TECHNICAL SPECIFICATIONS
CD/MP3/WMA PLAYER SECTION
Signal to Noise Ratio > 60 dB
Channel Separation > 50 dB (1kHz)
Frequency Response 20Hz - 20 kHz
TUNER (FM)
Frequency range 87.5-108 MHz
Intermediate frequency 10.7 MHz
Sensitivity 2.8 µV
Stereo separation 30 dB
Signal to noise ratio 50 dB
Channel step 50 kHz
TUNER (MW)
Frequency range 522-1620 KHz
Intermediate frequency 450 KHz
Usable Sensitivity 32 dBµV
LINE-OUT
Output 350mV
Impedance 10k Ohm
GENERAL
Power Supply 12V DC (10.8-15.6V allowable)
Speaker impedance 4 or 8 ohm
Output power 60W x 4CH
Note: Specication and the design are subject to possible modication without notice due to improvements.
RESET
How to Set Conversation Volume
1. Press and hold (*) button on the remote control then press and hold SEL button for 2 seconds.
2. Press SEL button repeatedly until “TEL” displays.
3. Rotate VOL knob to the desired level.
Disconnect Paired Devices
You can disconnect to an already paired Bluetooth device from your car stereo.
1. Press and hold (*) button on the remote control then press and hold SEL button for 2 seconds.
2. Press SEL button repeatedly until “DISCONN” displays.
3. Press and hold SEL button again to disconnect.
• RESET
Reset button is placed on the housing.
The reset button is to be activated for the following reason:
• Initial installation of the unit when all wiring is completed.
• All the function button do not operate.
• Error symbol on the display.
