LOCATION OF PARTS AND CONTROLS
1. POWER ON/OFF ( )
2. FUNCTION SELECT BUTTON: BASS/TREBLE/BALANCE/FADER/TA SEEK/MASK
DPI/RETUNE/AUDIO DSP/LOUDNESS/ESP/CD MULTI/SCROLL/BEEP/STEREO/
LOCAL/PAIRING
3. VOL UP/VOL DOWN FOR BASS/TREBLE/BALANCE/FADER/TA SEEK/MASK DPI/
RETUNE/AUDIO DSP/LOUDNESS/ESP/CD MULTI/SCROLL/BEEP/STEREO/LOCAL/
PAIRING
4. PRESET STATIONS (1,2,3,4,5,6)
5. ‘AF’ function (ALTERNATIVE FREQUENCIES)
6. ‘TA’ function (TRAFFIC ANNOUNCEMENT)
7. ‘PTY’ function (PROGRAM TYPE)
8. DISPLAY BUTTON (DISP)
9. MODE BUTTON (MD)
10. BAND BUTTON (BD)
11. AUTOMATIC OR MANUAL TUNING (FREQ UP OR FREQ DOWN /
CD TRACK/SEARCH BUTTON
12. AUTO SEEK SEARCH TUNING (A/PS)
13. ‘SCAN’ AUTOMATIC TUNING CONTROL (SCAN)
14. MUTE BUTTON (MU)
15. LCD DISPLAY
16. PANEL RELEASE BUTTON ( )
17. CD SLOT
18. CD EJECT BUTTON ( )
19. TOP BUTTON
20. PAUSE BUTTON
21. INTRO BUTTON (Preview all Tracks)
22. REPEAT BUTTON
23. RANDOM BUTTON
24, 25. + 10 TRACK SEARCH UP/DOWN
26. USB PORT
27. MULTI-MEDIA CARD (MMC) / SD CARD SLOT
DISP
BD/PAU
MD/MU
1 TOP
SCAN
IPS 247BT CD/MP3/WMA PLAYER 4x60WATTS
1517223141 9 2 18 27166
211912131020 11 23 24 25 8 7 265
4
(1-6)
DISP
BD/PAU
MD/MU
1 TOP
SCAN
IPS 247BT CD/MP3/WMA PLAYER 4x60WATTS
