Transportation and Storage
A. Cautions during Transportation
To transport the InBody970 safely, two people should keep the device in a horizontal position.
B. Repacking Instructions
Once the InBody970 is installed, avoid transporting the device. If it must be transported, repack it in the following
sequence.
1. Turn off InBody970.
2. Remove all connected adapters, cables, and the hinge cover. Press both gaps of the hinge cover, and press it slightly in
the vertical direction and pull it in the arrow direction.
3. Wrap the body of the InBody970 with a protective plastic wrap. Place a protective packaging material on the foot
electrodes and fold the upper part as shown in the gure below.
III.
Protective
PackagingVinyl
Protective
PackagingVinyl
Protective
Packaging
Material
❶
❷
