11
Num-
eric
Alpha-numeric
Protocol
Function: Default
Value:
Programmable
Range:
OP 60 Aut27 Auto-Reset after “FA 27” Unstable
Synchro Signal Error (page 50)
OFF On or OFF
OP 61
27rLY
Selects which relay will assert when the
“FA 27” error is active
OFF OFF, LO, HI
OP 62 OtGLt Sets On-Tap guard band limit (Degrees) 0.1 0.1 to 9999.9
OP 63 OtrLY Selects which relay will assert when the
On-Tap guard band limit is reached
OFF OFF, LO, HI
OP 64 OtdtE On-Tap reference date
Enter day, month, year
01–01–00
OP 65 OtdIS Scrolls through the list of taps, to select,
Press ENTER to display the highest
measured deviation, for that tap
Press MENU to escape back to the menu
Any valid tap
number
OP 66 Otdtd Scrolls through the list of taps which have
exceeded the On-Tap alarm limit to select,
Press ENTER to display the highest
measured deviation, for that tap
Press MENU to escape back to the menu
Any valid tap
number
OP 67 OtCLr Clears the On-Tap alarm CL
OP 68 OtrSt Resets all On-Tap logs & alarm rESEt
OP 70 udCLt Sets the alarm limit for the number of
changes UP TO any tap in THOUSANDS
000.01 000.01 to 999.99
OP 71 udrLY Selects which relay will assert when the
“UP TO” change alarm limit is reached
OFF OFF, LO, HI
OP 72 uddtE UP TO & DOWN TO Change counter
reference date Enter day, month, year
01–01–00
OP 73 uddIS Scrolls through the list of taps to select,
Press ENTER to display the Change Up-
To count Press ENTER to display the
Change Down-To count, for that tap
Press MENU to escape back to the menu
0 Any valid tap
number
OP 74 udCLr Clears an active Up-To and Down-To
Change alarm
CL
OP 75 udrSt Resets all Change Up-To and Down-To
counters and alarm
rESEt
OP 80 POrt Sets serial port parameters: (press the UP
or Down key to select a value, press the
enter key to move to the next parameter)
Baud rate
Word length
Parity (n=none, E=even, O=odd)
Stop bits
Address (for RS-485 Multi-drop)
9600
8
n
1
128
2400, 4800, 9600,
14400, 19200,
28800,38400,
57600, 76800
7 or 8
n, E, O
1 or 2
0 to 255
OP 85 PtnLt Sets the limit for number of days without a
“Pass Thru Neutral”
OFF Off, 0.1 to 365.0
OP 86 PtrLY Selects which relay will assert when the
“Pass Thru Neutral” time limit is reached
OFF OFF, LO, HI
OP 87 PtdIS Displays the number of days since the last
“Pass-Through-Neutral”
To Next Page
