Command Syntax: Function: Explanation:
DEGSEG◊n.nnnnª
Set degrees per segment n= a floating point number, 5 digits max,
average number of degrees between taps
NEUTRALS◊nª
Set number of neutral taps n= an integer from 0 to 8
NSTART◊nnª
Set lowest neutral tap number n= an integer, any valid tap number
SETTAP◊nnª
Set present tap position n= an integer, any valid tap number
LDTAPª
Load present tap pos. into memory
Must be done for SETTAP to take effect
DISPRL◊ONª
Enables the display of “r” (raised)
and “L” (lowered) tap numbers
“ON” or “OFF” When enabled causes
the display to show “r” and “L” in
function modes 20 and 21 only
ANACALª
Enter analog calibration mode, the
1250 analog output will be forced
to Low / Mid / High signal output
Press the space bar to toggle between
Low / Mid / High analog output. Press the
enter key to stop calibration
WDOGTESTª
Forces a Watchdog Reset This command is for factory use only.
LEDTESTª Turns on all display segments Press the enter key to stop the LED test
INCALª Self-calibrates the input circuitry Outputs “Pass” or “Fail” calibration
result
RLYTESTª Forces Hi / Lo relay output to
close
Press the Space Bar to toggle between
Lo or Hi relay Press ª (enter) to exit
DSPBL◊ONª
Enables the display blanking
feature
“ON” or “OFF” When enabled causes
the display to go blank after 60 sec.
SERIAL◊nª
Set serial communication mode 0=Serial Disabled, 1=Data Logger
Mode, 2=Polled Mode,
3=Sampled Mode,
4=Serial Command Mode, 5= Reserved,
6=MODBUS Mode, 7=Remote Display
Driver
AUTO25◊ONª
Enables automatic reset of the
“FA 25” Loss of Synchro Signal
Error (page 50)
“ON” or “OFF” When “ON”, the
“FA 25” alarm will automatically reset
when the condition clears
FA25RLY◊LOª
Selects which relay is associated
with the “FA 25” Error
Choose “OFF”, “LO” or “HI” relay to
assert when the FA 25 Error is active
RESET25ª Manually clears the “FA 25”
alarm
When AUTO25 is “OFF”, manually
clears the alarm and opens the relay
TTCLMT◊nnn.nnª
Sets the Total Tap Change count
alarm limit in THOUSANDS
n= a number from 0.00 to 999.99 with
two decimal place resolution
TTCRLY◊LOª
Selects which relay is associated
with the Total Tap Change count
alarm
Choose “OFF”, “LO” or “HI” relay to
assert when the alarm limit is reached
TTCPRE◊nnn.nnª
Presets the Total Tap Change
counter
in THOUSANDS
and clears the alarm
n= a number from 0.00 to 999.99 with
two decimal place resolution
TTCDATE◊mm-dd-yyyyª
Sets the Total Tap Change
counter reference date
mm-dd-yyyy = Month <hyphen> Day
<hyphen>Year (4 digits)
AUTO27◊ONª
Enables automatic reset of the
“FA 27” Unstable Synchro
Signal Error (page 50)
“ON” or “OFF” When “ON”, the
“FA 27” alarm will automatically reset
when the condition clears
FA27RLY◊LOª
Selects which relay is associated
with the “FA 27” Error
Choose “OFF”, “LO” or “HI” relay to
assert when the FA 27 Error is active
RESET27ª Manually clears the “FA 27”
alarm
When AUTO27 is “OFF”, manually
clears the alarm and opens the relay
