Incon 1250B User Manual

29
Register:
Hex:
Function:
Binary Format:
44103, 44104
Read/Write
1006,1007
analog high limit
bcdabcdbbcdcbcdd bcde000000vspppp
44353
Read/Write
1100
number of taps
000000000nnnnnnn 7 LSBs
44354, 44355
Read/Write
1101,1102
degrees per
segment
bcdabcdbbcdcbcdd bcde000000vspppp
44356
Read/Write
1103
number of
neutrals
000000000000nnnn 4 LSBs
44357
Read/Write
1104
neutral start
segment
ssssssssssssssss 16 bits, first neutral tap
44358
Read/Write
1105
display “r”&“L”
000000000000000d enabled, LSB(d)= 1
44609
Read/Write
1200
relays enable
000000000000000r enabled, LSB(r) = 1
44610, 44611
Read/Write
1201,1202
relay low limit
bcdabcdbbcdcbcdd bcde000000vspppp
44612, 44613
Read/Write
1203,1204
relay high limit
bcdabcdbbcdcbcdd bcde000000vspppp
44614
Read/Write
1205
relay low tap
ssssssssssssssss 16 bits, low tap limit
44615
Read/Write
1206
relay high tap
ssssssssssssssss 16 bits, high tap limit
44616, 44617
Read/Write
1207, 1208
rotation rate filter
threshold
bcdabcdbbcdcbcdd bcde000000vspppp
44618, 44619
Read/Write
1209, 120A
averaging filter
threshold
bcdabcdbbcdcbcdd bcde000000vspppp
44620, 44621
Read/Write
120B, 120C
averaging filter
depth
bcdabcdbbcdcbcdd bcde000000vspppp
44865, 44866
Read/Write
1300,1301
preset position
bcdabcdbbcdcbcdd bcde000000vspppp
44867
Read/Write
1302
preset tap
ssssssssssssssss 16 bits, preset tap no.
44868
Read/Write
1303
load/clear preset
control
0000000000000ccc 3 LSBs (ccc) select
000 – no operation
001 – clear offset
010 – load preset
45121
Read/Write
1400
display blank
000000000000000b enabled, LSB(b)=1
45122
Read/Write
1401
menu mode
000000000000000m LSB (m) select
0= numeric, 1=alphanumeric
45123
Read/Write
1402
auto reset FA25
000000000000000m LSB (m) select
0= Off, 1= On (Automatic Reset)
45633
Read/Write
1600
RS-232 mode
0000000000000rrr 3 LSBs (rrr) select
000=datalogger mode, 001=polled mode,
010=sampled mode, 011=command,
100=reserved N/A, 101=RS485 Modbus,
