23
ENGLISH
200 mm
50 mm
84,5 mm
115 mm
50 mm
200 mm
8,5 mm
DRILLING DIAGRAMS
SAFE 10 E PLUS SMART
PLACEMENT
Now it is possible to place the Safe over a piece of furniture or inside a wardrobe, locking it with 2
xing screws supplied in packing.
The Safe has 4 through holes for xing, 2 on the rear wall and 2 on the horizontal face, to be used
at the installer’s discretion, according to the place where the Safe will be placed.
Screw
