ASSISTANCE
23
GB
Service Manual
MOON - 2006
Linguage
English
Edition
2006.06.12
Dismantling the detergent dispenser
1. Open the door.
2. Pull the detergent drawer upwards.
3. Remove the 5 hooks (2 at the front, 3 at the rear)
that secure the dispenser plug.
4. Remove the fl oats by lifting them upwards.
Dismantling the conductivity sensor
1. Leave the tub empty.
2. Unplug the appliance from the mains power
supply and shut off the water tap.
3. Remove the cable from the conductivity sensor.
4. Unscrew the conductivity sensor.
