Service Manual UK
Indesit
Company
English
INTRODUCTION OF INDESIT TOUCH CONTROL HOB VIA640C
The above model was first produced in April 2008.
Production was changed from Italy to Poland in April 2012. A new Commercial Code was also
introduced.
Model No. Commercial Code Colour Country of Origin
VIA640C 53019 Black Frameless Glass Italy
VIA640C 79112 Black Frameless Glass Poland
TECHNICAL SPECIFICATIONS
General Touch control with 9 heat settings
4 residual heat indicators (stays on for as long as the zone is
at a temperature above 60°C
Position of Rating Plate
(Data Badge) Underside of base plate
Overall Dimensions
Width 590 mm
Depth 520 mm
Height 48 mm
Weight Packed - 12.5 kg, unpacked - 12.1 kg
Aperture Size
Width 560 ± 1 mm
Depth 490 ± 1 mm
Mains Cable Supplied 6 x 1.5 mm
2
Hotplate
Positions Rating (Watts)
Front Left 2200W
Rear Left 1400W
Rear Right 2200W
Front Right 1400W
Supply Voltage 230/240 Volts AC @ 50 Hz
Appliance Total Loading 7200W, 30 amps
