Service Manual UK
Indesit
Company
English
INSTALLATION & FASTENING
Taken from the Instructions for Installation and Use
The following instructions are intended for a qualified fitter to guide him/her along the installation,
adjustment and technical maintenance procedures as correctly as possible and in full compliance with
the applicable norms in force.
Important: Unplug the hob before all operations.
Installation
• This hob can be built into a worktop simply by cutting out the corresponding slot. See Fig. 1.
• The worktop must be made with a material designed to withstand a temperature of approximately
100°C.
• If you wish to install the hob on top of an oven, the latter must be fitted with a cooling fan.
• Try to avoid installing the hob on top of a dishwasher; if this is unavoidable, place a watertight
separating element between the two appliances.
560 +/- 1
490 +/- 1
48
590
5
2
0
Fig. 1
