7-7
d. Indmar-Vee Through Shaft. On these models,
you must remove the plug from the rear of the
V-drive to drain the cooler.
Figure 7.7 – Indmar-Vee Through Shaft Drain Plug
e. Walter V-Drive. On these models, you can drain
the water from the cooler by removing one of the
water drain plugs.
Figure 7.8 – Walter V-Drive Drain Plugs
INDM-0022
INDM-0026
