32
Insert either tongue into the buckle followed by the
other tongue until a “CLICK” is heard. Should the
second tongue not insert, press the red button and
reinsert the tongues. Ensure secure engagement by
pulling the harness strap (refer Figure 5).
Step 7:
Using Harness
Use
Infant Seat
“CLICK”
Figure 5
Figure 6
IMPORTANT
!
If no “Click” can be heard or a secure
engagement cannot be achieved refer to
Cleaning Buckle Harness page 43.
1
2
Remove all of the slack for the harness lap straps by
pulling shoulder straps (refer Figure 6), then pull the
harness adjustment strap to adjust harness to a
comfortable but rm t (refer Figure 7).
Step 8:
DO NOT LEAVE CHILDREN
UNATTENDED IN THE CAR.
Fit the harness rmly to the child.
A LOOSE RESTRAINT OR HARNESS
IS DANGEROUS.
WARNINGS
!
Figure 7
PULL TO
TIGHTEN
REMOVE ALL
SLACK FROM
HARNESS
Harness
Adjuster Strap
To Next Page
