Infasecure CS2113 - Placing Infant Carrier into Base

34
NOTE: Ensure the Release lever is visible.
Step 1:
Step 2:
Step 3:
Figure 1
Figure 2
Figure 3
Placing Infant Carrier into Base
Use
Infant Seat
Lift the Infant Carrier by the carry handle and
position over the top of the Base (refer Figure 1).
Make sure the harness adjustment strap is secured
on the securing slot on the plastic adjuster cover
(see Using Harness in Figure 10 on Page 33).
You need to ensure that this strap doesn’t get caught
between the Infant Carrier and Base.
Place the back heel of the Infant Carrier into the
Base rst , this will assist with aligning the Infant
Carrier with the two securing hooks on the Base
(refer Figure 2).
Press down on the Infant Carrier to engage the
securing hooks. Pull upwards on the Infant Carrier
to check it is correctly locked into position (refer
Figure 3).
PULL
TO CHECK
1
2
Release
lever
1
2
