Place the Infant Carrier on a at and secure surface.
Rotate the Carry Handle to the ‘Non –Rocking
Position’ (refer to Page 14) and the Hood is fully
opened, to enable complete access to the seat (refer
Figure 1).
Loosen the harness straps by pressing the harness
adjuster whilst pulling on both harness straps (Refer
Figure 2).
Release the buckle (refer Figure 3).
Lay the two harness straps (with tongues) to the
sides of the Infant Carrier .
Feed the infant’s arms through each of the harness
straps and lift the infant out of the Infant Carrier.
Removing Infant from Infant Carrier
Use
Infant Seat
Figure 2
Figure 3
Step 1:
Step 2:
Step 3:
Step 4:
Step 5:
Step 6:
Figure 1
TO
RELEASE
PULL
PRESS
