Infasecure CS4310 - CS4210;CS4310 Child Restraints (Itemised List)

CHILD
WITH INBUILT HARNESS
CS4210/CS4310
FORWARD FACING
IMPORTANT
!
UPPER ANCHORAGE STRAP ADJUSTER
UPPER ANCHORAGE STRAP
ATTACHMENT CLIP
ANCHOR FITTING + ATTACHMENT HARDWARE
SAFE GRIP RED BELT CLAMP (supplied in pocket)
VEHICLE SEAT BELT
“FORWARD-FACING SEAT BELT PATH” MARKER
(EACH SIDE OF RESTRAINT - COLOURED YELLOW)
COMFORT COVER
A - SEAT BASE
B - BACKREST
C - HEADREST
SHOULDER HEIGHT MARKER
HARNESS SHOULDER STRAPS
BUCKLE ASSEMBLY
HARNESS ADJUSTER
HARNESS ADJUSTMENT STRAP
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
For a vehicle without a xed parcel shelf an extension strap(s) may be needed.
If so ring (02) 4728 8080 for nearest supply location. (Refer page 42)
Seat belt extenders should not be used if the seat belt is not long enough to secure the child
restraint.
VIEW A
NOTE: Ensure the
seat belts are under the
foam padding and cover
VIEW A
8 A
6
9
10
11
12
13
9
5
REARWARD FACING
BELT PATH
FORWARD FACING
BELT PATH
SEAT BELT
PATH
Front
of Car
7
NOTE: Padded inserts can vary according to model. For detailed description and method of attachment for padded
accessories refer to Accessories on page 43-44.
8 B
8 C
Shoulder height markers are provided on this restraint for a visual indication that the child is safe to travel in this restraint.
Shoulder height markers may be hidden under the pillow or headrest, when in the lowest position.
1
2
3
4
