5. Service and Maintenance
5.2 Test Button and Indicator LEDs
INFiLED’s Wallpaper series uses indicator LEDs on the panels back. These are
one of the most important fault-finding tools.
The test button and indicator LEDs are located on the right side of the panel.
The test button is the small black knob besides the two LEDs. The red LED
indicates the power supply status, the green LED indicates the data
connection.
Notes about the indicator LED
Solid RED = Receiving Power
Flashing GREEN
(4 flashes per sec.)
= Data connection ok, no Signal
Flashing GREEN
(2 flashes per sec.)
= Receiving Signal
Flickering GREEN
(3 times per sec.)
= Transmitting calibration data
Test button functions
Briefly pressing = Start and stop of the testbattern
Repeatedly pressing = Switching between test images
Long pressing (10 sec.) = Transmitting calibration data
