1. Product Overview
1.4 Specifications
2019
INFiLED Wallpaper User’s manual
Modul Number IL-RSS-IRWP 1.2
Pixel Pitch 1,25 mm
Physical Density 640.000 pixel/m²
LED Arrangement 3in1 SMD
Module Resolution 240 x 135 pixels
Module Dimensions 300 x 168,75mm (11,81 x 6,64 in)
Cabinet Resolution 480 x 270 pixels
Cabinet Dimensions 600 x 337,5 x 29 mm (23,62 x 13,29 x 1,14 in)
Cabinet Weight 5.2 kg (11.46 lb)
Brightness 600 ~ 800 cd/m²
Max. Power Consumption 180 W/m²
Ave. Power Consumption 60 W/m²
Visual View Angel 160° / 160°
Operating Power Source 100 - 240 V, 50 - 60 Hz
Operating Temperature -10 °C - +45 °C
Refresh Rate ≤ 3.840 Hz
Life Span 100.000 h
MTBF 5.000 h
IP Rating IP30
Max. Rigging 17 cabinets
Signal Input Source
Composite s-video, Component, VGA, DVI, HDMI, SDI,
HD-SDI
Verification CE, RoHs, ETL, FCC
