CONTENT
4
SAFETY INFORMATION
1. PRODUCT OVERVIEW
1.1 FEATURES 5
1.2 DIMENSIONS 6
1.3 EXTERNAL COMPONENTS 7
1.4 SPECIFICATIONS 8
1.5 PACKAGE 9
2. MECHANICAL INSTALLATION
2.1 VERTICAL CONNECTION 10
2.2 HORIZONTAL CONNECTION 12
2.3 INSTALLATION COMPONENTS 13
2.4 SMALL SCREEN INSTALLATION 16
2.5 BIG SCREEN INSTALLATION 17
2.6 LED-PANEL SUSPENSION 18
3. POWER AND DATA CONNECTION
3.1 ELECTRICAL COMPONENTS 19
3.2 POWER AND DATA LINK 20
4. SOFTWARE
4.1 SENDERBOARD 23
4.2 HARDWARE CONNECTION 24
4.3 SOFTWARE INTRODUCTION 25
5. SERVICE AND MAINTENANCE
5.1 MAINTENANCE ANNOUNCEMENT 32
5.2 TEST BUTTON AND INDICATOR LEDs 33
5.3 TROUBLESHOOTING 34
5.4 SERVICE DESK 35
2019
INFiLED Wallpaper User’s manual
