2. INTERFACES
KPM210/216
22-
KPM80/112
SIGNAL GND
RXD
DCD
CTS
DSR
KPM80/112 PC
TXD
The diagrams below illustrate a sample connection between the printer and
PC using a 25- or 9-pin female connector.
(Fig.2.2)
(Fig.2.3)
(Tab.A.3)
