3. PRINTER FUNCTIONS
KPM210/216
343-
in ram.
n selects the graphic source as follows:
nnoitcnuF
0marmorfegapcihpargtnirP
)tnemomehttadesu(
1hsalfmorf1ogoltnirP
The maximum printable vertical dimension dhmax is :
• for the 204 dpi model dhmax = 315
• for the 300 dpi model dhmax = 212
xL + xH × 256 specifies the starting dotline ( 1 ÷ dhmax).
yL + yH × 256 specifies the number of lines to print.
[Notes] • If (xL + (xH × 256)) > dhmax the printer does not execute
the command.
• If ( xL + ( xH × 256 ) + yL +( yH × 256 ))> dhmax the printer
prints only dhmax - xL + ( xH × 256 ) +1 dotline.
• After the print of the logo from RAM (n= 0 ), the graphic
page is deleted. If the user wants to print again or save the
logo into the flash, the user must retransmit or reload it with
the command ESC ³.
• To print a text string before the logo, send a LF, because
the logo printing buffer and the characters buffer is the same.
• If don’t modify the logo stored into flash bank, use this
command with n = 1.
[Default]
[Reference] ESC ³, ESC ², ESC ¦
[Example] To print from ram bank dotline 100 to dotline 199, send:
1BH FAH 00H 00H 64H 00H C7H
HnLn¹CSEHnLn¹CSE
HnLn¹CSE
HnLn¹CSEHnLn¹CSE
[Name] Transmit graphic page to communication port
[Format] ASCII ESC ¹ nL nH
Hex 1B FB nL nH
Decimal 27 251 nL nH
[Description] Transmits [nL + (nH × 256)] word of graphic page used at the
moment to the communication port.
(Tab.A.3)
