3. PRINTER FUNCTIONS
KPM210/216
303-
ESC 2 or ESC 3.
• The maximum paper feed amount is 254 rows. Even if a
paper feed amount of more than 254 rows is set, the printer
feeds the paper only 254 rows.
[Default]
[Reference] ESC 2, ESC 3
[Example]
iCSEiCSE
iCSE
iCSEiCSE
[Name] Total cut
[Format] ASCII ESC i
Hex 1B 69
Decimal 27 105
[Description] This command prints the data in the buffer and enables cutter
operation. If there is no cutter, a disabling flag is set and any
subsequent cut commands will be ignored.
[Notes] • The printer waits to complete all paper movement com-
mands before it executes a total cut.
[Default]
[Reference]
[Example]
ntCSEntCSE
ntCSE
ntCSEntCSE
[Name] Select character code table
[Format] ASCII ESCt n
Hex 1B 74 n
Decimal 27 116 n
[Range] n = 0, 2, 3, 4, 5, 19, 255
[Description] Selects a page n from the character code table, as follows:
(Tab.A.3)
