3. PRINTER FUNCTIONS
KPM210/216
503-
[Notes] m must be sent with n = 3;
with n = 3 if the ticket is not yet cutted, before to perform the
command, the printer made a total cut.
[Reference]
[Example] The correct commands sequence to print a ticket is :
1. Clear dispenser
Ejection (Hex : 1D 65 05) or Retraction (Hex : 1D 65 02)
2. Prints ticket
3. Cuts paper
Total cut (Hex : 1B 69)
4. Dispense
Presents ticket (Hex : 1D 65 03 00)
nfSGnfSG
nfSG
nfSGnfSG
[Name] Select font for HRI characters
[Format] ASCII GS f n
Hex 1D 66 n
Decimal 29 102 n
[Range] n = 0, 1, 48, 49
[Description] Selects a font for the HRI characters used when printing a
bar code.
n selects a font from the following table:
ntnoF
84,0AtnoF
94,1BtnoF
[Notes] HRI characters are printed at the position specified by GS H.
[Default] n = 0
[Reference] GS H, GS k
[Example]
(Tab.A.3)
