Infiniton CMPP-RU92 - Introduction and Technical Drawing of the Chimney Hood

7
2. INTRODUCTION AND TECHNICAL DRAWING OF THE CHIMNEY HOOD
E
F
1. Duct
2. Control panel
3. Filter
4. Lighting
A 170 mm
B 200 mm
C 700 mm
D 25 mm
E 450 mm
F 596 mm / 896 mm
1
2
3
4
A
B
C
D
