Page 8
Do not install the appliance where strong wind blows, or it can cause flame out
or incomplete combustion, subsequently cause fire accident and flue gas
intoxication.
Installation Method
1. Installation
Drill holes in the wall according to Fig.5, it’s
recommended to drill the 2 upper holes first and
ensure they’re horizontal. Put 2 expansion bolts into
the above holes and hang the appliance on them,
then mark up the position for the lower hole and put
down the appliance. Drill the 3
rd
hole and put a
plastic tube into it, and then fix the appliance
vertically on the upper bolts and tighten all the bolts
the screws.
2. Piping
It’s mandatory to have a pressure reducer before the gas inlet, and the
specification of the reducer must be corresponding to the normal pressure
specified in the technical label. If the appliance is installed in a gas pipeline, the
pressure reducer might already be installed by the gas supplier.
Gas Inlet
Please connect the gas inlet connector and the gas pressure-reducer with flame
To Next Page
