Reference 5761a Electrical Parts List Addendum
The following chart below represents the only electrical parts
differences in 5760a and 5761a models:
MODEL PART NAME PART NUMBER SPEC DESIGNATOR
REF 5760a RESISTOR RES-00-00415 1/5WF 12K OHM R171,271,371,471
1
REF 5761a RESISTOR RES-00-00480 1/5WF 27K OHM R171,271,371,471
REF 5760a RESISTOR RES-00-00467 1/5WF 22K OHM R571,671
2
REF 5761a RESISTOR RES-00-00532 1/5WF 43K OHM R571,671
REF 5760a RESISTOR RES-08-00225 SMD 0805 1/10WJ 820 OHM R108,208,308,408,508,608
3
REF 5761a RESISTOR RES-08-00242 SMD 0805 1/10WF 240 OHM R108,208,308,408,508,608
REF 5760a RESISTOR RES-08-00253
SMD 0805 1/10WF
15.2KOHM
R155,255,355,455,555,655
4
REF 5761a RESISTOR RES-08-00116 SMD 0805 1/10WF 9.1KOHM R155,255,355,455,555,655
REF 5760a
POWER TERMINAL
TER-00-00030 (3P) TM006-01 TER1
5
REF 5761a
POWER TERMINAL
TER-00-00278 (3P) DK-03B04-AG-5-UP TER1
REF 5760a
SPEAKER TERMINAL
TER-00-00020 (12P) WT-9512 TER2
6
REF 5761a
SPEAKER
TERMINAL
TER-00-00272 (12P) DK-1201-AG-5-UP TER2
