PREPARATION BEFORE USING
Installation method
Step 1: Take out the components of massage chair
Open the main carton, and take out the quilting product packages,
accessory carton and the main body of the massage chair carefully.
Check whether the components are complete (please check one by
one according to the packing list)
Step 2: Install left and right armrests
The connection of armrest and armrest shelf: Aim the three connection
sticks of armrest to the three eccentric joints on the armrest shelf, then
press downwards on the armrest and fasten it by the eccentric joint.
(If the rear screws are hided by back cover, so they can't be fastened,
please power on the chair to raise the back). It is the same installation
method for the other armrest.
Armrest
Armrest shelf
Eccentric
joint
connection
stick
clockwise
fastening
Eccentric joint structure
connect air tube port under the armrest to its corresponding output
air tube. (It is the same way for the other side)
Air tube port
Air tube
15. working indicator of reclining motor for backrest and legrest
16. back massage position mode:
Full back massage: cover the entire back
Partial back massage: centralized as current massage point,
the massage range takes up one third of the full back
Fixed point massage: under manual mode, choose fixed point
massage to repeat the current massage technique or previous
ones.
17. back massage width indication
3 width adjustable: narrow, medium, wide
18. back massage speed indication
6 degrees adjustable
19. Vibration(twist) strength indication
3 degrees adjustable
20. Airbag intensity indication
5 degrees adjustable
21. back heating indication
22. seat twist indication
narrow, medium, wide
NAME AND FUNCTION OF EACH COMPONENT
