PREPARATION BEFORE USING
The connection of armrest locks with backrest.
Hold up the rear part of the armrest, push inward to let the gap of
armrest lock aim at armrest spindle, then push the armrest to fasten
them together.(Press downward the handle of the lock to unlock
armrest and backrest)
Armrest lock Handle of the lock
Make sure the 4 connection sticks completely inserted into the
eccentric joints, then use cross screwdriver to fasten the armrest by
turning 180 clockwise.( The sharp point on the eccentric joint shall
point downward ) It is the same installation method for the
other armrest.
The connection of
eccentric joints
1 2
3
4
5 6
7
8
9
10
NAME AND FUNCTION OF EACH COMPONENT
1.Time display: It shows working time upon the start of massage with
defaulted time of 20 minutes.
2.Recovery indicator
3.Refresh indicator.
4.Extend indicator
5.Relax indicator
Under the massage modes: Recovery, Refresh, Extend or Relax, the icon
will be on, but not under other modes.
6.Shoulder position adjustment indicator
During body shape sensing, after it automatically senses on the back part
of shoulder, this area is lighted to remind the user to micro adjust shoulder
poison by Shoulder Up/down adjustment
7.USB Flash disk connection indicator
8.MP3 Volume indicator
9.Massage modes: to show present massage mode
VFD display description
10.Zero Gravity cylinder performance indicator: lie upwards;return
downwards.
11. Rolling masage on sole indication
12. Body sensing status indication
13. Part of airbag massage dynamical indiction
14. Massage dynamical indication
Kneading ,tapping ,sync ,knocking ,shiatsu , music
15
16
17
18
19
20
11
12
13 14
22 21
