Infinity BassLink II - Electrical Parts List

BASSLINK II Electrical Parts List
Part Numbers Description
Qt
y
Reference Designators
POWER SUPPLY/MAIN PCB
Resistors
110-14102j26 Resistor 1K 1/4W ±5% CF 26mm 1 R561
110-16102j26 Resistor 1K 1/6W ±5% CF 26mm 1 R560
110-16103j26 Resistor 10K 1/6W ±5% CF 26mm 1 R540
110-16154j26 Resistor 150K 1/6W ±5% CF 26mm 1 R80A
110-16182j26 Resistor 1.8K 1/6W ±5% CF 26mm 1 R74A
110-16203j26 Resistor 20K 1/6W ±5% CF 26mm 2 R563,564
110-16220j26 Resistor 22Ω1/6W ±5% CF 26mm 4 R526,527,528,529
110-16221j26 Resistor 220Ω1/6W ±5% CF 26mm 1 R76A
110-16473j26 Resistor 47K 1/6W ±5% CF 26mm 1 R77A
110-16682j26 Resistor 6.8K 1/6W ±5% CF 26mm 1 R77C
116-1410r0j26x metal film Resistor 10Ω 1/4W 26mm 1 R615
116-142201j26x metal film Resistor 2.2K 1/4W ±5% MO 26mm 2 R532,534
113-50r12j00 cement Resistor 0.12ohm 5W ±5% 1 R82A
113-50r18j00 cement Resistor 0.18Ω 5W ±5% 1 R81A
116-101000j20x metal film Resistor 1W 100Ω 5% 1 R539
116-303300jk2x metal film Resistor 330Ω 3W 5% 10mm 2 R531,533
Capacitors
135-c158m35-e electrolytic cap 1500uF 35V ±20% 105℃13mm*25mm (RoH 2 C501A,501B
135-c337m35 electrolytic cap 330uF 35V ±20% 105℃ 1 C561
138-5228m801 large aluminum ec 2200uF 80±20% ψ25*30 2 C521,523
129-a334j633 metalized capacitor 0.33uF 63V±5% MSC 1 C562
130-2b101k503 disc capacitor 100P 50V ±10% 3 C335,336,337
130-2b221mj03 disc capacitor 220P 1000V ±20% 1 C539
130-3f104z503 disc capacitor 0.1U 50V +80/-20% 4 C502,533,535,540
130-3f222k503 disc capacitor 0.0022uF(2.2NF) 50V ±10% 1 C560
132-104ja03 mylar capacitor 0.1UF 100V±5% 3 C526,537,538
132-372ja03 mylar capacitor 0.027UF 100V±5% 1 C60A
135-3476m50 electrolytic cap 47uF 50V ±20% 4 C531,532,534,536
140-ax104ka03 multi-layer capacitor 0.1uF 100V X7R ±10% 2 C104A,C524
130-3f104z503 disc capacitor 0.1U 50V +80/-20% 1
Semiconductors
192-161tip31c transistor TIP31C SGS NPN 1 Q531
192-162tip32c transistor TIP32C SGS PNP 1 Q532
192-16360nf06 transistor STP60NF06 SGS FET 4 Q508,509,510,511
197-141n4004 diode IN4004 1 D50
197-301604gd diode SF1604G-D 2 D511,512
192-027c2235y transistor 2SC2235Y NPN 1 Q16A
197-0131n4148 transistor IN4148 26mm 1 D52A
199-05001505j zener diode 400mW 15V ROHM 52mm IN5254B 2 Z501,502
Miscellaneous
109-1ttc802j0 thermister TTC-802(JS)NTC 1 TH501
120-1000003 inductor 10W AI YT-C3104-005 1CRHW 354708LTB 3 B500,501,502
122-14106m130 inductor MIZI R251510 3*ψ1.3 1.0mH 1 L500
150-r36231504 transformer RT36-6T:28T 1 T500
171-u833h1cc relay 833H-IC-C 12VDC 1 RL50
175-1c12v01 coupling 12PIN PITCH=2.5mm 1 M300
176-ft205 wire connector pin FASTON M#205 2 SP-,A,
176-ft250 wire connector pin FASTON M#250 2 SP+,B,
359-FIB-00004 gasket 26*8*1.5T 4
193-0s080020 insulator 80*20*0.3t 2
Powered Subwoofer Basslink II
12
