Infinity BassLink II - Page 14

Part Numbers Description
Qt
y
Reference Designators
POWER SUPPLY/MAIN PCB
193-0s4211 insulator (INSULATION SPACER)42*11 1
193-201612tr insulator TO-220 16mm*12mm 3 for Q10,10B,11
236-AL-05001 AL patten 1
317-000-00037 terminal T=0.3 1
323-AL-05042-0BA heat sink 218*100*21(H) 1
323-AL-05043-1LA heat sink 177*93*73MM 1
333-EVA-00216 EVA PACKING(G)15*25*3T 2 TO thermister-2
333-EVA-05144-1BAE EVA 199.63*10*3T black (RoHS) 2
333-EVA-05145-2BAE EVA98*8.5*3T (RoHS) 2
351-AM03005A015 screw M3*0.5P*5L 4 PCB -H/S-4
351-AM03016A097 M3*16 screw 4 heat -holder-4
351-AM03022A958 screw M3*22 2 Toclass-D-2
352-BM04006E975 screw T45*6 8 "L"H/S-H/S-8
361-FE-05000 IC bracket 69*12*4*1.5T 1
361-FE-05050-0LA IC bracket 64*12*1.5T 1
362-CU-05029-0YA PCB interval batten 5.5L*5.5W*6.5H 4 PCB-H/S-4
JACK/LIMITER PCBs
Resistors
110-16102j26 Resistor 1K 1/6W±5% CF 26mm 1 R52
110-16103j26 Resistor 10K 1/6W±5% CF 26mm 18
R47,48,49,50,285,294,302,307
R309,330,5,6,7,8,23,24,25,26
110-16104j26 Resistor 100K 1/6W±5% CF 26mm 10 R301,27,28,29,30,31,32,33,34,36
110-16122j26 Resistor 1.2K 1/6W±5% CF 26mm 1 R295
110-16123j26 Resistor 12K 1/6W±5% CF 26mm 1 R234
110-16151j26 Resistor 150Ω 1/6W±5% CF 26mm 2 R310,311
110-16153j26 Resistor 15K 1/6W±5% CF 26mm 2 R304,328
110-16154j26 Resistor 150K 1/6W±5% CF 26mm 1 R329
110-16183j26 Resistor 18K 1/6W±5% CF 26mm 1 R274
110-16222j26 Resistor 2.2K 1/6W±5% CF 26mm 5 R37,38,39,40,228
110-16223j26 Resistor 22K 1/6W±5% CF 26mm 18
R17,18,41,42,43,44,45,46,254,287
R9,10,11,12,13,14,15,16
110-16273j26 Resistor 27K 1/6W±5% CF 26mm 2 R257,273
110-16303j26 Resistor 30K 1/6W±5% CF 26mm 1 R305
110-16333j26 Resistor 33K 1/6W±5% CF 26mm 1 R277
110-16472j26 Resistor 4.7K 1/6W±5% CF 26mm 10 R275,276,1,2,3,4,19,20,21,22
110-16473j26 Resistor 47K 1/6W±5% CF 26mm 2 R14A,290
110-16474j26 Resistor 470K 1/6W±5% CF 26mm 1 R278
110-16511j26 Resistor 510Ω 1/6W±5% CF 26mm 4 R256,586,303,306
110-16512j26 Resistor 5.1K 1/6W±5% CF 26mm 2 R312,51
110-16562j26 Resistor 5.6K 1/6W±5% CF 26mm 1 R238
110-16563j26 Resistor 56K 1/6W±5% CF 26mm 1 R237
110-16755j26 Resistor 7.5M 1/6W±5% CF 26mm 1 R293
116-167871f26 metal film Resistor 7.87K 1/6W MF 26mm 1 R279
Capacitors
135-0477m35 electrolytic cap 470uF 35V ±20% 1 C503
137-3106m35-e mini aluminum ec 10uF 35V 85℃ ± 20% ψ5*5 (RoHS) 2 C50,C53
130-2b101k503 disc capacitor 100P 50V ±10% 18
C4,11,12,17,18,20,23,24,26,29,30
C32,214,253,330,331,333,334
130-2b470k503 disc capacitor 47P 50V ±10% 4 C3,19,25,31
130-3f104z503 disc capacitor 0.1U 50V +80/-20% 11
C5,6,39,40,41,43,268
C269,301,303,501
132-103j503 mylar capacitor 0.01uF 50V ±5% 5 C252,270,271,500,504
132-153j503 mylar capacitor 0.015U 50V ±5% 1 C33
135-3105m50 electrolytic cap 1U 50V ±20% 1 C311
135-3106m50 electrolytic cap 1uF 50V ±20% 11
C7,8,34,272,273,300
C302,13,14,15,16
