Part Numbers Description
Qt
y
Reference Designators
JACK/LIMITER PCBs
135-3226m50 electrolytic cap 22U 50V ±20% 9 C1,2,9,10,21,22,27,28,264
135-3475m50 electrolytic cap 4.7U 50V ±20% 1 C312
135-3476m50 electrolytic cap 47uF 50V ±20% 1 C251
137-3106m35-e mini aluminum ec 10uF 35V 85℃ ± 20% ψ5*5 (RoHS) 2 C52,C51
Semiconductors
190-06m13700n I.C. NJM13700N JRC Dual Op Transconductance Amplifier 1 U301
190-06m45581d I.C.NJRC NJM4558LD Dual Op-amp 3 U1,2,3
190-16t1074cn I.C TL074CN ST Quad Op-amp 1 U203
195-10204hd L.E.D red 3mm FOR STANDBY 1 LD200
197-306a20 diode 6A 200V 6A20 1 D502
192-027c1815gr transistor 2SC1815GR NPN 3 Q200,201,301
192-028a1015gr transistor 2SA1015GR PNP 1 Q202
197-031n4148 diode IN4148 26mm 6 D201,202,1,2,3,4
Miscellaneous
154-k025a800 fuse 25A 32V ATC UL/CSA 1 F500
155-9f30240 fuse holder F30240100P 1 for F500
162-10402003 wire ass'y 400mm 12AWG BLACK#250 W/ TUBE SLEEVE 1 BAT+F
162-10430001 wire ass'y 430mm 12AWG BLACK#205 W/ TUBE SLEEVE 1 A
162-5020c003 wire ass'y 200mm#2468 26AWG 9PIN 1 WB1
162-5045c001 UL wire ass'y 450mm #2468 26AWG 12PIN 1 W300
162-a030d001 wire ass'y 300mm 16AWG 1 BAT+,BAT-
174-0b402p RCA JACK B402P 1 JK1
174-535913sg-1 DC JACK BASSLINK II 1 JK500
174-9mjd0604 jack M/JACK D/S 6P4C BLACK 6U 1 JK4
175-9c08v01 coupling 8PIN PITCH=2.5mm 1 W200
175-9f10v02 coupling 10PIN black PITCH=2.54mm PHFY-10SB-S032 2 W301,302
175-9f10v22a coupling PIN HEADER 10PIN black P=2.54mm 2 M301,302
175-9h04v01 coupling 4PIN PITCH=4.2mm 2 JK2,3
180-s570050 switch SS70050-0202-10T-NN 2 SW1,2
359-FIB-00005 gasket ODψ8*3.5T 2
362-NYL-05030-0WA interval batten LDE 12H LEDS-12 1
333-EVA-05156-0BA EVA gasket 42.5*3*1mm 2
333-EVA-05157-0BA EVA gasket 174*3*1mm 2
333-SPG-00850 foam 50*5*200mm 1
333-SPG-00860 foam 450*50*5T 1
333-SPG-00875 foam 250*50*5T 1
333-SPG-00876 foam 400*50*5T 1
362-CU-05034-0YA coppet postψ5.5*ψ5.5*12.4H 6 PCB TO PCB-6
362-NYL-05006-0WA interval batten 10H(MAE-10T;HAKUTO-10)white 6 PCB-PCB-6
PWM/CONTROL PCB
Resistors
110-16100j26 Resistor 10ΩK 1/6W±5% CF 26mm 3 R521,523,613
110-16102j26 Resistor 1K 1/6W±5% CF 26mm 4 R424,502,519,629
110-16103j26 Resistor 10K 1/6W±5% CF 26mm 12
R507,508,511,611,612,616,621
R622,623,625,626,627
110-16104j26 Resistor 100K 1/6W±5% CF 26mm 4 R517,614,618,624
110-16105j26 Resistor 1M 1/6W±5% CF 26mm 2 R420,422
110-16106j26 Resistor 10M 1/6W±5% CF 26mm 1 R421
110-16123j26 Resistor 12K 1/6W±5% CF 26mm 1 R513
110-16152j26 Resistor 1.5K 1/6W±5% CF 26mm 1 R550
110-16221j26 Resistor 220ΩK 1/6W±5% CF 26mm 1 R501
110-16222j26 Resistor 2.2K 1/6W±5% CF 26mm 1 R515
110-16223j26 Resistor 22K 1/6W±5% CF 26mm 1 R628
110-16393j26 Resistor 39K 1/6W±5% CF 26mm 1 R631
Powered Subwoofer Basslink II
14
