Part Numbers Description
Qt
y
Reference Designators
PWM/CONTROL PCB
110-16432j26 Resistor 4.3K 1/6W±5% CF 26mm 1 R505
110-16433j26 Resistor 43K 1/6W±5% CF 26mm 1 R503
110-16471j26 Resistor 470ΩK 1/6W±5% CF 26mm 3 R510,522,524
110-16472j26 Resistor 4.7K 1/6W±5% CF 26mm 1 R520
110-16512j26 Resistor 5.1K 1/6W±5% CF 26mm 1 R514
110-16562j26 Resistor 5.6K 1/6W±5% CF 26mm 2 R518,630
110-16681j26 Resistor 680ΩK 1/6W±5% CF 26mm 1 R504
110-16682j26 Resistor 6.8K 1/6W±5% CF 26mm 1 R516
110-16683j26 Resistor 68K 1/6W±5% CF 26mm 1 R538
110-16751j26 Resistor 750ΩK 1/6W±5% CF 26mm 1 R509
116-161001f26 metal film Resistor 1K 1/6W±1% MF26mm 2 R541,542
116-161132f26 metal film Resistor 11.3K 1/6W±1%MF26mm 1 R512
116-1410r0j5vx metal film Resistor 10Ω 1/4W ±5% 1 R500
Capacitors
129-a105j633 metalized capacitor 1uF 63V ±5% MSC 1 C505
130-2b102k503 disc capacitor 1000P 50V±10% 1 C420
130-2b272k503 disc capacitor 2700pF 50V±10% 1 C507
130-2b472k503 disc cappacitor 4700P 50V ±10% 2 C511,624
130-3f104z503 disc capacitor 0.1U 50V +80/-20% 10
C503,506,509,510,512,542
C611,621,623,625
135-3106m50 electrolytic cap 10uF 50V ±20% 1 C422
135-3226m50 electrolytic cap 22U 50V ±20% 1 C508
135-3337m10 electrolytic cap 330U 10V ±20% 1 C612
135-3337m16 electrolytic cap 330uF 16V ±20% 1 C622
135-3476m50 electrolytic cap 47uF 50V ±20% 1 C421
137-3227m25 mini aluminum ec 220uF 25V ±20% 1 C504
Semiconductors
192-027c1815gr transistor 2SC1815GR NPN 11
Q404,406,501,503,514,610
Q611,612,622,624,626
192-028a1015gr transistor 2SA1015GR PNP 6 Q502,504,505,621,623,625
192-028a965y transistor 2SA965Y PNP 1 Q500
197-031n4148 diode IN4148 26mm 7 D503,540,550,552,611,612,613
199-15000625 zener diode 6.2V 1/2W 52mm 1 Z500
190-13494cn IC TL494CN PWM 1 U500
190-99pc817c IC PC817C(COSMO) Opticoupler 1 U501
192-027c1815gr transistor 2SC1815GR NPN 2 Q405,513
192-028a1015gr transistor 2SA1015GR PNP 1 Q506
Miscellaneous
175-9f40hr2 coupling 40PIN PITCH=2.54mm HR2*40 0.4 M501,502
GAIN PCB
Resistors
115-h503b109 variable Resistor RD-901F-20-19KW-B50K-00D Gain, Bass 2 VR201,202
115-h503b214 variable Resistor RD-902F-20-19KW-B50K-00D Crossover 1 VR203
110-16102j26 Resistor 1K 1/6W±5% CF 26mm 3 R219,222,233
110-16103j26 Resistor 10K 1/6W±5% CF 26mm 2 R221,229
110-16123j26 Resistor 12K 1/6W±5% CF 26mm 1 R227
110-16153j26 Resistor 15K 1/6W±5% CF 26mm 1 R218
110-16202j26 Resistor 2K 1/6W±5% CF 26mm 1 R200
110-16223j26 Resistor 22K 1/6W±5% CF 26mm 2 R240,241
110-16243j26 Resistor 24K 1/6W±5% CF 26mm 1 R225
110-16392j26 Resistor 3.9K 1/6W±5% CF 26mm 1 R224
110-16393j26
Resistor 39K 1/6W±5% CF 26mm
1 R223
Powered Subwoofer Basslink II
15
