Infinity BassLink II - Page 17

Part Numbers Description
Qt
y
Reference Designators
GAIN PCB
110-16473j26 Resistor 47K 1/6W±5% CF 26mm 2 R251,253
110-16474j26 Resistor 470K 1/6W±5% CF 26mm 1 R220
110-16622j26 Resistor 6.2K 1/6W ±5% CF 26mm 2 R250,252
Capacitors
129-a104j633 metalized capacitor 0.1U 63V±5%MSTCAP 1 C211
129-a224j633 metalized capacitor 0.22uF 63V±5%MSC 1 C215
129-a274j633 metalized capacitor 0.27uF 63V±5% 4 C260,261,262,263
129-a394j633 metalized capacitor 0.39uF 63V±5%MSTCAP 1 C210
129-a823j633 metalized capacitor 0.082U 63V±5%MSC 1 C216
130-2b101k503 disc capacitor 100P 50V ±10% 4 C242,281,282,283
130-3f104z503 disc capacitor 0.1U 50V +80/-20% 6 C229,230,233,234,235,274
132-102j503 mylar capacitor 0.001U 50V±5% 1 C280
132-103j503 mylar capacitor 0.01uF 50V±5% 1 C217
137-3106m50 mini aluminum ec 10uF 50V ±20%
4
C228,230,266,267
Semiconductors
190-06m4558d I.C. OPA 4558D Dual Op-amp 3 U200,204,205
195-10204ubd L.E.D 204-10UBD Power 1 LD500
Miscellaneous
361-NYL-05049-0WA LEDψ3*6 1 socket for LD500
162-a045d002-e wire ass'y (RoHS) 1 M200
398-CU-05128-0BAE control knob airtight cover PC+10%Gf black (RoHS) 1
CLASS D AMP
118-12061001j SMD Resistor 1.00K 1206 5% 1 R2
118-12061002j SMD Resistor 10.0K 1206 5% 6 R25,29,30,30B,7,9
118-120610r0j SMD Resistor 10.0Ω 1206 5% 4 R20,20B,22,23
118-12062002j SMD Resistor 20.0K 1206 5% 1 R26
110-12062201j SMD Resistor 2.20K 1206 5% 19
R6,13,16,31,33,34,35,36,37,38
R39,40,41,42,43,44,45,46,32
118-12062204j SMD Resistor 2.20M 1206 5% 1 R4
118-12062701j SMD Resistor 2.70K 1206 5% 1 R10
118-12063000j SMD Resistor 300.0Ω 1206 5% 1 R24
118-12063301j SMD Resistor 3.30K 1206 5% 5 R1,14,15,27,28
118-12063902j SMD Resistor 39.0K 1206 5% 1 R3
118-12064700j SMD Resistor 470Ω 1206 5% 3 R8,11,21
118-12064701j SMD Resistor 4.70K 1206 5% 2 R5,12
Capacitors
141-c0101k50 SMD Capacitor 100pF 50V10% 1206 NPO 1 C4
141-c0220k50 SMD Capacitor 22pF 50V10% 1206 SMT NPO 1 C5
141-c0561k50 SMD Capacitor 560pF 50V10% 1206 NPO 1 C6
141-c5104m50 SMD Capacitor 1206 Y5V 0.1uF 50V±20% 8 C2,3,7,8,9,10,11,15
141-c7223k50 SMD Capacitor 0.022uF 50V 10%1206 X7R 1 C13
141-d7104ka0 SMD Capacitor 0.1uF 100V 10%1210 X7R 4 C12,14,18,19
128-e106ma01-s non-polar ec 10uF 10V 20% 2 C16,17
132-104kb50 mylar capacitor 0.1U±10% 250V LS-1.mmMD 1 C20
132-105kb50 mylar capacitor 1uF 250V ±10% 1 C40
Semiconductors
190-16t1072dts SMD I.C.TL072CDT SGS THOMSON Dual Op-amp 1 IC1
192-09124126qs SMD transistor 2SC2412K-T146Q/R ROHM 2 Q1,4
192-09139066rs SMD transistor 2SC3906K-T146R ROHM 2 Q2,8
Powered Subwoofer Basslink II
16
