Part Numbers Description
Qt
y
Reference Designators
CLASS D AMP
192-091sc4672 transistor 2SC4672(MPT3)ROHM 1 Q5B
192-092130376qs SMD transistor 2SA1037K-T146Q/R ROHM 2 Q7,9
192-09215146rs SMD transistor 2SA1514K-T146R ROHM 1 Q3
192-1582n5401 transistor FSC 2N5401 AI-PNP 350V 500mA TO-92 1 Q6B
197-03r1s4148s SMD diode RLS4148-TEII ROHM 8 D1,2,3,4,5,5B,6,20
199-15000563s SMD ZENER 5.6V 5%PHILIPS BZX84-C5V6 2 Z1,Z2
199-15001203s SMD ZENER 12V 5% PHILIPS BZX84-C12 4 Z3,4,5,6
192-232irf9640 FET IRF9640 IF P-CH T0220 2 Q10,10B
192-233f640n FET IRF640N INTERNATIONAL 1 Q11
Miscellaneous
122-13151k0190 CHOKE SA-500-280(PT1601B*151MAA) 1 L1
122-14300k4 Ferrite core LD1215*300KU*±10% 1 L2
175-9f40hr2 coupling 40PIN PITCH=2.54mm HR2*40
Powered Subwoofer Basslink II
17
