Amplifier Specifications| amplifier power | 250Wrms |
|---|---|
| frequency response | 20Hz to 120Hz |
| fuse | 30A |
| max current draw | 26A |
| idle current draw | < 800mA |
| input sensitivity line-level | 50mV to 4V |
| input sensitivity high-level | 1V to 16V |
| crossover frequency | 50Hz to 120Hz |
| crossover slope | 12dB per octave |
| bass boost | –6dB to +3dB @ 40Hz |
Weight and Dimensions| dimensions | 40-3/8" x 6-7/16" x 14-3/8" (1026mm x 164mm x 366mm) |
|---|
