Infinity BassLink T User Manual

6
INSTALLATION
CONNECTING THE REMOTE LEVEL CONTROL
TO BASSLINK T
The Remote Level Control may be mounted
under the dash or may be dismantled and
mounted in the dash for a factory appearance.
UNDER-DASH MOUNTING
Select a mounting location that allows easy
access to the control while driving. Using the
Remote Level Control as a template, mark and
drill holes in the mounting surface. Attach the
Remote Level Control using the mounting screws
provided (Figure 10).
Figure 10. Under-dash mounting of the Remote
Level Control.
IN-DASH MOUNTING
Disassemble the Remote Level Control by
removing the two Phillips-head screws on the
front panel, rear panel and on top. Remove the
Remote Level Control’s bottom and side panels.
Slide the Remote Level Control’s PC board
forward to release the RJ11 connector from the
back panel and remove the board along with the
potentiometer, knob and connector as a single
assembly.
Choose a mounting location that allows easy
access to the control, and provides 1-3/4"
clearance behind the mounting surface. Drill
a 9/32" hole in the mounting surface. Feed the
Remote Level Control’s potentiometer (with the
knob removed) through the hole and use the nut
provided to hold the control in place (Figure 11).
Figure 11. In-dash mounting of the Remote Level
Control.
Route the cable behind the dash or other interior
panels and under the carpet. Do not route the
cable outside the vehicle. Connect the RJ11 cable
between the RJ11 receptacle on the BassLink T
and the receptacle on the Remote Level Control
(Figure 12).
Figure 12. Remote Level Control electrical
connection.
POWER
+BATT REM GND
FUSE
25A
REMOTE
LEVEL
CONTROL
LINE LEVEL
INPUT
HIGH LEVEL
INPUT
+
R
–
+
L
–
L R
BassLink T
(Control Panel)
BassLink T OM 10/13/04 2:21 PM Page 6

Infinity BassLink T Specifications

Amplifier Specifications

amplifier power	250Wrms
frequency response	20Hz to 120Hz
fuse	30A
max current draw	26A
idle current draw	< 800mA
input sensitivity line-level	50mV to 4V
input sensitivity high-level	1V to 16V
crossover frequency	50Hz to 120Hz
crossover slope	12dB per octave
bass boost	–6dB to +3dB @ 40Hz

Weight and Dimensions

dimensions	40-3/8" x 6-7/16" x 14-3/8" (1026mm x 164mm x 366mm)
