Infinity Beta SW Series User Manual

CSW-10 120/230v Electrical parts list
Part number Qty Description Reference Designator
MAIN PCB
Resistors
021-100401-020 1 MOF Resistor 1K 1W J FK TYPE R173
021-560305-020 1 MOF Resistor 560R 5WS J 8x25 KINK R76
022-005105-020 1 Resistor PN:SQM 0R05 5W J 25x13 R2
022-470307-020 1 Winding resistor KNP 470R 7W J (KNP-700S) R78
024-000098-120 1 SMD Resistor 0R 1/8W J 0805 R8
024-100498-120 1 SMD Resistor 1K 1/8W J 0805 R110
024-100598-120 15 SMD Resistor 10K 1/8W J 0805 R5,7,16,118,121,122,125,1,
024-100698-120 2 SMD Resistor 100K 1/8W J 0805 R15,120
024-110598-120 4 SMD Resistor 11K 1/8W J 0805 R187,188,190,191
024-130498-120 2 SMDResistor 1K3 1/W J 0805 R189,192
024-150598-120 2 SMDResistor 15K 1/8W J 0805 R20,21
024-160598-100 2 SMDResistor 16K 1/8W F 0805 R13,13B
024-220298-120 2 SMDResistor 22R 1/8W J 0805 R28,29
024-220498-120 1 SMD Resistor 2K2 1/4W J 1206 R119
024-220498-121 2 SMD Resistor 2K2 1/8W J 0805 R17,31
024-220598-120 2 SMD Resistor 22K 1/8W J 0805 R127,37
024-330498-120 4 SMD Resistor 3K3 1/8W J 0805 R77,79,22,169
024-330598-120 5 SMD Resistor 33K 1/8W J 0805 R4,6,14,60,60B
024-412498-100 1 SMD Resistor 4K12 1/8W F 0805 R63
024-470298-120 4 SMD Resistor 47R 1/8W J 0805 R24-27
024-470398-120 4 SMD Resistor 470R 1/8W J 0805 R145,155,177,186
024-470598-120 2 SMD Resistor 47K 1/8W J 0805 R3,171
024-510498-120 5 SMD Resistor 5K1 1/8W J 0805 R48A,48B,48C,48D,48E
024-560498-120 1 SMD Resistor 5K6 1/8W J 0805 R30
024-680498-120 1 SMD Resistor 6K8 1/8W J 0805 R23
Capacitors
031-100144-106F 2 SMD Cap. 0u01/50V K 0805 X7R C27,28
031-100184-100F 2 SMD Cap. 0u01/250V K 0805 X7R C104,119
031-100344-100F 6 SMD Cap. 0u1/50V K 0805 X7R C10,69,112,115,135,138
031-100384-100F 2 SMD Cap. 0u1/250V K 1206 X7R C5,6
031-220344-300F 1 SMD Cap. 220pF/50V K 0805 NPO C40
031-470144-101F 1 SMD Cap. 0u0047/50V K 0805 X7R C1G1
034-100614-300 1 Electrolytic Cap. 100uF/16V M (R)0611 P:2.5 C8
034-100625-300 1 Electrolytic Cap. 100uF/25V M (R)6.3x11 P:5 C62
034-100695-300 1 Electrolytic Cap. 100uF/63V M (R)1012 P:5 C142
034-220525-300 2 Electrolytic Cap. 22uF/25V M (R)5x11 P:2.5 TAPIN C25,26
034-330625-300 2 Electrolytic Cap. 330uF/25V M (R)1013 P:5 C11,100
034-470415-300 1 Electrolytic Cap. 4u7/50V M (R)0511 P:2.0 C7
032-100484-200 3 ENDMylar Capacitor 1uF/250V K P:15 C37,39,30
033-330444-270 2 NPE Cap. 3u3/50V K10 (R)8x13 SBE C114,137
033-680464-270 2 NPE Cap. 6u8/100V K10 (R)1020 GNE C113,136
034-150895-200 2 Electrolytic cap. 85 15000uF/63V M (R)3555 P:10mm C1,4
Semiconductors
054-000100-100 6 SMD DIODE PN:ES1D 200V 1A D1,23,37,40,44,47
054-001002-100 1 SMD ZENER DIODE PN:BZX84C10 10V SOT-23 D32
054-001501-100 2 SMD ZENER DIODE PN:BZX84C15 15V SOT-23 D2,3
054-033904-100 6 SMD Transistor PN:MMBT3904LT1 SOT23 (ON Q25,28,29,37,50,51
054-033906-100 5 SMD Transistor PN:MMBT3906LT1 SOT23 (ON Q26,27,30,36,52
CSW-10
20
