Infinity Beta SW Series User Manual

Part number Qty Description Reference Designator
MAIN PCB
054-050601-100 1 SMD ZENER DIODE PN:BZX84C5V6 5.6V SOT-23 TAPIN D30
054-414803-100 16 SMD DIODE PN:LL4148 (Wishay) D4-5,13,14,21,22,31,33,38,
054-540100-100 1 SMD Transistor (PNP) PN:MMBT5401 LT1 SOT-23 Q1
054-555100-100 1 SMD Transistor (NPN) PN:MMBT5551 LT1 (ON) Q2
051-000600-100 1 Transistor NPN PN:MPSW06RLRA TO-92 (ON) Q6
051-005600-100 1 Transistor PNP PN:MPSW56RLRA TO-92 (ON) Q8
051-290700-100 4 Transistor PNP (ON) PN:MPS2907A RLRA TO-92 Q12,14,16,18
051-540101-000 1 Transistor PNP(FAIRCHILD PN:2N5401 TO-92 Q3
051-002301-000 4 MOSFET N CHANNEL PN:FB23N20D Q11,13,15,17
052-400080-000 1 Bridge Regulator PN:RS804 400V,8A BR1
053-257400-100 1 IC;DIP,Regulator PN:LM2574 HVN-15V 8PIN (NS) U6
Miscellaneous
044-100100-000 2 SMD FERRITE BEAD PN:321611 600R/100MHz 1206 FB1,FB2
043-300101-000 2 INDUCTOR PN:YT-10033 30uH L9,10
043-560200-000 1 INDUCTOR 56uH YT-10779 L12
043-700100-000 1 INDUCTOR 70uHx2 YT-10024 L8
043-820300-000 1 INDUCTOR 820uH YT-10034 L1
025-010300-000 1 Thermister TSE-103 K L:50mm TH1
025-210100-000 1 Thermister (PTC) PN:PTMS2101RP516B TH2
072-040008-110 1 8P Terminal housing JS-1001-08 P1
072-040039-000 1 Terminal (PCB TYPE) PC205 (t=0.8m/m) T205MA T1
072-040064-000 2 Terminal (PCB TYPE) PC250(t=0.8),T250MA T2,TER6
072-040096-000 2 Terminal T187MA(PCB) (t=0.8mm) PC187(0.8) TER5,TER7
073-111003-000 1 Shorting Strap 54.9x13.6x1mm J7
073-111004-000 2 Shorting Strap 29.5x12.4x0.8m/m J4,9
074-300018-000 1 RELAY PN:943-1C-48D RLY1
DRIVER PCB
024-000098-120 4 SMD Resistor 0R 1/8W J 0805 R313,314,318,320,
024-100298-120 4 SMD Resistor 10R 1/8W J 0805 R89,90,140,150
024-100498-120 10 SMD Resistor 1K 1/8W J 0805 R81,85,96,97,131,137,142,
024-100598-120 12 SMD Resistor 10K 1/8W J 0805 R75,82,83,92,98,132,133,
024-100798-120 2 SMD Resistor 1M 1/8W J 0805 R32,33
024-110598-120 2 SMD Resistor 11K 1/8W J 0805 R74,99
024-200598-120 2 SMD Resistor 20K 1/8W J 0805 R95,141
024-220398-120 2 SMD Resistor 220R 1/8W J 0805 R136,167
024-220498-121 1 SMD Resistor 2K2 1/8W J 0805 R134
024-220598-120 1 SMD Resistor 22K 1/8W J 0805 R37
024-220798-120 2 SMD Resistor 2M2 1/8W J 0805 R87,93
024-270498-120 3 SMD Resistor 2K7 1/8W J 0805 R80,84,157
024-390498-120 2 SMD Resistor 3K9 1/8W J 0805 R130,161
024-390598-120 2 SMD Resistor 39K 1/8W J 0805 R86,94
024-470398-120 1 SMD Resistor 470R 1/8W J 0805 R91
024-470498-120 6 SMD Resistor 4K7 1/8W J 0805 R151-153,183,34,36
024-470598-120 1 SMD Resistor 47K 1/8W J 0805 R35
024-560598-120 1 SMD Resistor 56K 1/8W J 0805 R38
024-680498-120 2 SMD Resistor 6K8 1/8W J 0805 R135,166
Capacitors
034-100625-303 1 Electrolytic Cap. 100uF/25V M (R) P:2.5 C117
034-100715-202 2 Electrolytic Cap. 85 1000uF/16V M (R)1017 P:5 C109,132
CSW-10
21
