Infinity Beta SW Series User Manual

Part number Qty Description Reference Designator
DRIVER PCB
034-330615-301 1 Electrolytic Cap. 330uF/16V M (R)0812 P:3.5 C32
031-100144-106F 4 SMD Cap. 0u01/50V K 0805 X7R C108,118,131,140
031-100343-100F 2 SMD Cap. 100pF/50V J 0805 NPO C81,84
031-100344-100F 6 SMD Cap. 0u1/50V K 0805 X7R C75-78,82,85
031-180344-100F 2 SMD Cap. 0u18/50V K 0805 X7R C80,83
031-470244-102F 4 SMD Cap. 0u047/50V K 0805 X7R C93,94,101,124
031-560243-100F 4 SMD Cap. 56pF/50V J 0805 NPO C92,102,105,125
031-560343-101F 1 SMD Cap. 560pF/50V J 1206 X7R C79
Semiconductors
051-000600-100 1 Transistor NPN PN:MPSW06RLRA TO-92 (ON) Q31
051-222200-100 2 Trasistor NPN (ON SEM) PN:MPS2222ARLRA TO-92 Q20,22
051-555100-000 2 Transistor NPN PN:2N5551 TO-92 Q21,23
053-211100-000 2 IC;DIP,DRIVER PN:IR2111 8PIN (IR) U7,8
054-000100-100 2 SMD DIODE PN:ES1D 200V 1A D35,43
054-001002-100 2 SMD ZENER DIODE PN:BZX84C10 10V SOT-23 D42,49
054-005501-100 1 SMD ZENER DIODE PN:BZV55C3V6 (PHILIPS) D60
054-007200-100L 2 SMD IC; DUAL OP-AMP PN:M072M-TE1 DMP8 (JRC) U9,10
054-033906-100 2 SMD PNP Transistor PN:MMBT3906LT1 SOT23 (ON Q34,35
054-050601-100 2 SMD ZENER DIODE PN:BZX84C5V6 5.6V SOT-23 TAPIN Z7,8
054-414803-100 5 SMD DIODE PN:LL4148 (Wishay) D36,39,46,52,61
054-540100-100 2 SMD Transistor (PNP) PN:MMBT5401 LT1 SOT-23 Q33,40
054-555100-100 1 SMD Transistor (NPN) PN:MMBT5551 LT1 (ON) Q32
Miscellaneous
072-040229-000 1 HEADER Right Angle PN:211-107-000-400 7PIN PIN2
072-040230-000 1 HEADER Right Angle PN:211-111-000-400 11PIN PIN1
PREAMP/RABOS PCB
021-100398-100 1 MF Resistor 100R 1/8W F R339
021-100498-100 2 MF Resistor 1K 1/8W F R363,381
021-100598-100 9 MF Resistor 10K 1/8W F R338,342,343,346,348,353,
021-100798-100 1 MF Resistor 1M 1/8W F R356
021-100898-100 1 MF Resistor 10M 1/8W F R362
021-110698-100 1 MF Resistor 110K 1/8W F R347
021-120598-100 2 MF Resistor 12K 1/8W F R354,369
021-140598-100 1 MF Resistor 14K 1/8W F R380
021-150198-100 1 MF Resistor 1K5 1/8W F R341
021-162398-100 1 MF Resistor 162R 1/8W F R384
021-267498-100 1 MF Resistor 2K67 1/8W F R336
021-330498-100 1 MF Resistor 3K3 1/8W F R204
021-330598-100 1 MF Resistor 33K 1/8W F R383
021-340398-100 2 MF Resistor 340R 1/8W F R357,371
021-357498-100 1 MF Resistor 3K57 1/8W F R335
021-470598-100 1 MF Resistor 47K 1/8W F R214
021-549398-100 1 MF Resistor 549R 1/8W F R344
021-590498-100 1 MF Resistor 5K9 1/8W F R382
021-619498-100 2 MF Resistor 6K19 1/8W F R359,374
021-680398-100 1 MF Resistor 680R 1/8W F R360
021-787398-100 2 MF Resistor 787R 1/8W F R350,364
021-909398-100 1 MF Resistor 909R 1/8W F R385
021-931498-100 1 MF Resistor 9K31 1/8W F R351
CSW-10
22
