Infinity Beta SW Series User Manual

Part number Qty Description Reference Designator
PREAMP/RABOS PCB
024-000097-120 3 SMD Resistor 0R 1/4W J 1206 R302,303,297
024-100498-121 3 SMD Resistor 1K 1/4W J 1206 R238,264,298
024-100598-121 14 SMD Resistor 10K 1/4W J 1206 R202,206,207,212,222,
024-150498-121 1 SMD Resistor 1K5 1/4W J 1206 R251
024-150598-121 1 SMD Resistor 15K 1/4W J 1206 R223
024-200598-121 1 SMD Resistor 20K 1/4W J 1206 R256
024-220298-121 1 SMD Resistor 22R 1/4W J 1206 R249
024-226598-100 4 SMD Resistor 22K6 1/4W F 1206 R208,209,231,232
024-237597-100 1 SMD Resistor 23K7 1/4W F 1206 R281
024-270498-121 1 SMD Resitor 2K7 1/4W J 1206 R237
024-300398-121 1 SMD Resistor 300R 1/4W J 1206 R258
024-300598-121 1 SMD Resistor 30K 1/4W J 1206 R260
024-330498-101 2 SMD Resistor 3K3 1/4W F 1206 R203,215
024-330498-121 1 SMD Resistor 3K3 1/4W J 1206 R240
024-470598-120 2 SMD Resistor 47K 1/8W J 0805 R280,283
024-470698-121 1 SMD Resistor 470K 1/4W J 1206 R259
024-470798-120 1 SMD Resistor 4M7 1/8W J 0805 R244
024-470798-121 1 SMD Resistor 4M7 1/4W J 1206 R243
024-510398-121 1 SMD Resitor 510R 1/4W J 1206 R261
024-560598-121 1 SMD Resistor 56K 1/4W J 1206 R224
024-620398-121 2 SMD Resistor 620R 1/4W J 1206 R221,226
024-680498-121 1 SMD Resistor 6K8 1/4W J 1206 R247
024-680598-121 1 SMD Resistor 68K 1/4W J 1206 R250
024-820598-121 1 SMD Resistor 82K 1/4W J 1206 R263
031-100244-101F 4 SMD Resistor 0u01/50V K 1206 X7R C12,13,224,280
031-100344-102F 7 SMD Resistor 0u1/50V K 1206 X7R C227,229,230,232-235
031-100344-104F 1 SMD Resistor 100pF/50V K NPO 1206 C222
031-100345-300F 2 SMD Resistor 0u1/50V M 1206 X7R C305,306
031-220344-103F 4 SMD Resistor 220pF/50V K NPO 1206 C200,210,215,216
031-330445-100F 1 SMD Resistor 3300pF/50V M 1206 X7R C281
031-470444-101F 1 SMD Resistor 4700pF/50V K X7R 1206 C2G1
031-680444-100F 1 SMD Resistor 6800pF/50V K X7R 1206 C212
026-100595-001 2 VR 10KAx2 (NOBLE) XV012311YGPJ25F15A10K-21PC/1 VR302,303
026-100595-002 1 VR 10KCx2 (NOBLE) XV012311YGPJ25F15C10K-21PC/1 VR301
026-500595-254 1 VR 50KA P/N:RK163111R405-EJ R216
026-500595-267 1 VR 50KBx4 PN:RD1631411001D-50KBx4 (EJ) R233
Capacitors
034-100515-300G 1 Electrolytic Cap. 10uF/16V M (R)0511 P:2 C220
034-100615-301 1 Electrolytic Cap. 100uF/16V M (R)0611 P:5 C221
034-220516-301 2 Electrolytic Cap. 22uF/16V M (R)0511 P:2 C223,225
034-220525-300 4 Electrolytic Cap. 22uF/25V M (R)5x11 P:2.5 TAPIN C303,304,14,15
035-100363-300 5 PE Cap. 0u1/100V J P:5m/m C322,323,328,380,381
035-220243-100 1 PECap. FE-M 0u022/63V J P:5m/m C202
035-330293-300 2 PE Cap. 0u033/63V J P:5 C209,218
035-470353-301 2 PE Cap FE-M 0u47/63V J P:5m/m C207,208
035-680253-300 2 PE Cap FE-M 0u068/63V J P:5m/m C201,213
Semiconductors
054-007200-100L 7 SMD IC; DUAL OP-AMP PN:M072M-TE1 DMP8 (JRC) U200-205,301
054-007400-100 1 SMD IC; QUAD OP-AMP PN:TL074CDR (TI) U300
054-011400-100 1 SMD NPN Transistor PN:DTC114TKA SMT3 (ROHM Q202
054-033904-100 2 SMD NPN Transistor PN:MMBT3904LT1 SOT23 (ON Q203,204
CSW-10
23
