Infinity Beta SW Series User Manual

Part number Qty Description Reference Designator
PREAMP/RABOS PCB
054-414803-100 8 SMD DIODE PN:LL4148 (Wishay) D201,204,207,209,212,216,
050-505200-001 1 LED PN:LT-2402-21 LED1
Miscellaneous
072-010058-000 1 RCA JACK 2P PN:0502000W1G (Red,White) J201
072-040007-000 2 7P Terminal hous SWA101 JS-1001-07 P3,4
072-040008-110 1 8P Terminal housing JS-1001-08 P2
073-010021-000 3 Screw fixing house PN:PCB-2(M3) 4PIN T1,2,3
074-030002-000 3 TOGGLE SW PN:L101-T2B4QE SW200-202
FUSE PCB
043-324300-000 1 INDUCTOR 324uH YT-10778 L13
072-040064-000 1 Terminal (PCB TYPE) PC250(t=0.8),T250MA TER2
072-040096-000 3 Terninal T187MA(PCB) (t=0.8mm) PC187(0.8) TER1,3,4
039-220180-100 1 X2 Safety Cap. 0u22/250V 18x16.5x8.5mm PN:XG275M224VHS2 CXAC1
073-050001-000 2 FUSE CLIP P/N:CFFH1206 F1,B1
091-000200-000 1 FUSE (230V) T2.5A/250V φ5x20m/m F1
093-205205-300 1 FUSE (120V) T5A/250V φ5x20m/m, 120V version F1
MISCELLANEOUS
008-060302-072 4 GASKET (UL) PORON PN:MO-48C 25x18 t=5mm PSA X'FORMER
008-061215-000 1 GASKET C4305 12x15 t=5mm CR PSA Thermister
008-062401-032 4 GASKET 235.3x11mm t=2mm PSA COVERx2,PANELx2
008-062501-022 4 GASKET 253.3x11mm t=2mm PSA COVERx2,PANELx2
042-010139-000 1 Transformer PN:YT-13438 CSW-10 120V/60Hz PT1
042-010142-000 1 Transformer PN:PT-3034 CSW-10 230V/50Hz PT1
061-001052-000 2 Knob w/white dot indicator PN:49001-W (18teeth)D=15.1 H=14.5 R233,216
061-016001-000 3 φ16x14.8mm D TYPE P.P+TPR for VR301-303
061-100016-000 3 Partition PN:BCMS-8 L=8mm NYLON 66(UL) Power PCB
061-314002-000 2 Strain Relief P/N SB4F-2 PANEL,COVER
061-700044-000 2 Mica 13x18mm TO-220 holeless for Q13,17
061-700090-900 2 Ceramic Gasket 16x21mm t=2mm alum. Oxide, wht for Q11,15
062-252506-000 1 Bucket (CSW-10) 10"x10"x4.89" HIPS UL94 V0 blk
063-010010-000 5 Bracket for IC P/N:TRK-2 for Q11,13,15,17,TH1
063-252604-900 1 Panel 10"x10"x.0984" SPCC silver painting
073-014084-500 1 Bracket 6.64"x3.5"x3.2" SPCC cadium plated
074-020018-000 1 ROCKER SW (POWER) PN:RF1003-BB4-0 SW4
082-022611-000 1 Wire set #26 UL1007 L=110mm blk+whtx6 XH7Px2 RABOS TO PRE
082-082620-000 1 Wire set #26 UL1007 L=200mm XH8Px2 Blk/wht MAIN TO PRE
086-021836-000 1 Power Cord SPT-2 #18 12feet+T187 sleeve
181-911800-338 1 Wire set #18AWG UL1007 blk L=110mm Ring type C211
181-921400-002 1 Wire set #14AWG UL1015 blk 625mm T205/T205(t=0.8)+ sleeve SPE-
181-921422-002 1 Wire set #14AWG UL1015 red 625mm T250/T250+ sleeve SPE+
181-921600-000 1 Blk Wire #16 UL1015 T187 transparent sleeve L:140mm FUSE TO SW
181-921699-000 1 Wht wire #16 UL1015 T187 transparent sleeve L:160mm FUSE TO SW
CSW-10
24
