Page #24 background image
Overture 1
24
Resistors
RS2153 1 Potentiometer 20Kohm 20% Bass Gain
RS2369 1 POTENTIOMETER 1Kohm Bias Adj
RS2463 1 RES CEMENT 20Kohm 5% 5W
RS2151 1 RES M/O F/P 1Kohm 5% 2W
RS2296 2 RES M/O F/P 62Kohm 5% 2W
RS2301 2 Res Fuse 0.47 ohm 5% T/R
RS1058 1 RES M/F 51.1Kohm 1% 1/4W
RS1063 1 RES M/F 1 Mohm 1% 1/4W
RS1150 1 RES M/F 43.2Kohm 1% 1/4W
RS1153 1 RES M/F 47.5Kohm 1% 1/4W
RS1161 1 RES M/F 11Kohm 1% 1/4W
RS1342 2 RES M/F 9.09Kohm 1% 1/4W
RS1351 1 RES M/F 13Kohm 1% 1/4W
RS1353 2 RES M/F 3.01Kohm 1% 1/4W
RS1455 2 RES M/F 150Kohm 1% 1/4W
RS1492 1 RES M/F 221Kohm 1% 1/4W
RS1505 1 RES M/F 475Kohm 1% 1/4W
RS2018 5 RES M/F 10Kohm 1% 1/4W
RS2025 2 RES M/F 9.31Kohm 1% 1/4W
RS2125 2 RES M/F 59Kohm 1% 1/4W
RS2127 1 RES M/F 12.4Kohm 1% 1/4W
RS2129 1 RES M/F 5.49Kohm 1% 1/4W
RS2132 1 RES M/F 21.5Kohm 1% 1/4W
RS2141 1 RES M/F 110Kohm 1% 1/4W
RS2142 3 RES M/F 100Kohm 1% 1/4W
RS2143 2 RES M/F 3.32Kohm 1% 1/4W
RS2144 2 RES M/F 1.3Kohm 1% 1/4W
RS2146 1 RES M/F 1.5Mohm 1% 1/4W
RS2147 1 RES M/F 249Kohm 1% 1/4W
RS2149 2 Res. Fuse 1Kohm 5% 1/4W T
RS2152 1 RES M/F 75Kohm 1% 1/4W
RS2181 2 RES M/F 2.21Mohm 1% 1/4W
RS2295 1 RES M/F 511 ohm 1% 1/4W
RS2297 1 RES M/F 3.3Mohm 1% 1/4W
RS2298 1 RES M/F 301Kohm 1% 1/4W
RS2299 1 RES M/F 1.4Kohm 1% 1/4W
RS2300 1 RES M/F 374Kohm 1% 1/4W
RS2302 1 RES M/F 4.42Kohm 1% 1/4W
RS2304 2 Res Fuse 2Kohm 5% 1/3W T/
RS2305 1 Res Fuse 75 ohm 5% 1/3W T
RS2306 3 Res Fuse 6.8Kohm 5% 1/3W
RS2307 1 RES M/F 182Kohm 1% 1/4W
RS2139 1 RES M/F 200 ohm 1% 1/4W
Electrical Parts List (230v)
Part# Qty Description
