Infinity Compositions Series User Manual

Overture 1
23
Semiconductors
DI1186 1 Diode Zener 36V 5% 5W T/R
IC1045 1 Three-Term. Adj. Pos. V R LM317T
IC1215 2 IC TL064CN Quad OP AMP
IC1216 1 IC TL062CP Dual OP Amp.
TR1002 3 NPN Transistor TO-92 2N3904
TR1017 4 Transistor PNP T/R 2N3906
TR1316 3 Xsistor ZTX658
TR1317 1 Xsistor ZTX758
TR1318 2 Pwr Mosfet STH16NA40FI
TR1304 1 NPN XSTR 60V/3A 25W
DI1003 2 Diode Rectifier 1N4004
DI1004 1 DIODE ZENER 6.2V 1/2W T/R
DI1060 8 Diode Switching 500mW 75V
DI1224 1 DIODE PWR RECT 800V/3A
LE1034 1 Led Green/Red Common Cath
Capacitors
CP1126 1 CAP POLY FILM 1uF 10% 50V
CP1630 1 Cap Alum El 220uF 20% 25v
CP1656 1 Cap. Al El 100uF 20% NPE
CP1659 1 Cap. NPE 10uF 20% 25V T/R
CP1661 1 Cap. Alum El. 100uF 20% 5
CP1662 5 Cap. Alum El. 10uF 20% 35
CP1663 1 Cap. Alum El. 47uF 20% 25
CP1664 1 Cap. Alum EL. 4.70uF 20%
CP1666 2 Cap Cer Disc 68pF 20% 500
CP1669 1 Cap. Poly Fil .10uF 10% 4
CP1670 1 Cap. Poly Fil .039uF 5% 5
CP1672 3 Cap Poly 0.22uF 5% 63V T/
CP1673 1 Cap. Pol Fil 1nF 10% 50V
CP1674 1 Cap. Alum El. 1uF 20% 50V
CP1675 6 Cap. Pol Fil 0.1uF 5% 50V
CP1804 1 Cap Alum El 270uF 400V
CP1805 1 Cap Alum El 22uF 20% 100V
CP1806 1 Cap Poly Fil 0.22uF 10% 4
CP1807 1 Cap Al El 22uF 20% 250V
CP1829 1 Cap Al El 4.7uF 20% 100V
CP1828 1 Cap Alum El 390uF 20% 200
CP1846 1 CAP POLY FILM 56nF 5%
CP1658 3 Cap. Disc 100pF 10% 500V
CP1904 1 CAP POLY 0.022uF 20% 250V
Electrical Parts List (230v)
Part# Qty Description
