Infinity Compositions Series User Manual

Overture 1
9
Mechanical/Packaging Parts List
1 CABINET NOT FOR SALE
2 SCREW, 8-32 x1/2 6 60673
3 1” (25mm) HIGH FREQUENCY TRANSDUCER, DCR=4.0 Ohms±10% 1 333232-001
4 WOOFER GRILLE 1 330956-001
5 MD/TWT ISOLATOR CUP 1 331914-001
6 FRONT BAFFLE 1 331181-001
7 SCREW, 6-32 x 3/8, PPHMS, CADCAD PLATED 8 10811
8 OVERTURE 1 AMPLIFIER 1 NOT FOR SALE
9 BAR 1 332091-001
11 SCREW, 6-32 x .5, MS, PPH, BLACK 6 900301-008
12 NUT, 8-32, KEP HEX, ZINC 2 907102-001
13 DACRON-1407 63991
14 WOOFER
(120v) 8” (203mm) WOOFER, DCR=14.1 Ohms±10% 1 331663-001*
(230v) 8” (203mm) WOOFER, DCR=28.0 Ohms±10% 1 333385-001
15 4” (101mm) MIDRANGE TRANSDUCER, DCR=7.3 Ohms±10% 2 330638-001
16 FOAM, MIDRANGE CUP 2 324324-001
17 GRILLE RETAINER, KIT, (4 PCS) 1 332162-001
18 GASKET, WOOFER 2 332204-001
19 WASHER, #6, FL 4 11638
20 CLAMP, WOOFER 6 332032-001
21 CROSSOVER NETWORK (120V) 1 331211-001
CROSSOVER NETWORK (230V) 1 333580-001
22 GAIN KNOB 1 146-8021
23 INPUT BINDING POST (RED) 1 331723-001
24 INPUT BINDING POST (BLACK) 1 331724-001
25 LOGO 1 332622-001
26 FRONT GRILLE 1 331185-001
PACKAGING
27 FOAM END PAD TOP AND BOTTOM 2 331213-001
28 FRONT GRILLE 1 331185-001
29 ACCESSORY KIT (See separate parts below) N/A
FOOT W/ ADHESIVE 332337-001
RUBBER FRONT FOOT 332068-001
FOOT, BUMP-ON, SQ, BLK. 1/8 X ½” 332182-001
FOOT, BUMP-ON, SQ, BLK. 1/4 X ½” 332183-001
SLOT PLUG 332067-001
FUSE 3A SLO-BLO 250V (120V) 1 331630-001
FUSE 1.6A SLO-BLOW 250V (230V) 1 333398-001
30 OUTER CARTON, (120V) 1 331212-001
OUTER CARTON, (230V) 1 333393-001
31 BAG, ZIPLOCK 1 315953-001
32 OWNER’S MANUAL (120V) 1 331214-001
OWNER’S MANUAL (230V) 1 333390-001
33 SURVEY CARD 1 330033-001
34 SAFETY SHEET 1 330100-001
Optional Center Stand 1 332518-001
Optional wall mount bracket can be obtained from:
OMNIMOUNT CO.
Model 100 WIN-1
OMNIMOUNT phone# (602) 829-8000
* 8” WOOFER (120v) part# 331663-001 represents the latest revision of low frequency transducer.
Earlier version, cast frame 8” WOOFER, part# 331284-001 is NLA.
Ref No. Description Qty Part No.
