Page #22 background image
Overture 1
22
RS2158 1 RES M/F 3.3K ohm 5% 1/4W T/R R75
RS2181 2 RES M/F 2.21M ohm 1% 1/4W T/R R28, 31
RS2153 1 Potentiometer 20K ohm 20% BASS GAIN P1
RS2154 1 Potentiometer 2K ohm BIAS ADJ P2
Miscellaneous
MI1155 1 Transformer, Coupling T1
TH1017 1 Inrush Current Limiter 5A @10 ohms CL1
VA1009 1 Varistor 200V MOV1
BR1412 1 Clamp Transistor
BR1416 1 Plate Amp
BR1419 1 BAR AMP ASSY.
FH1004 1 Fuseholder 2AG Chassis Mount FH1
FS1064 1 Fuse Slo-Blo 3A/250v 2AG F1
HS1144 1 Heatsink Snowball 97-1
NU1049 8 Nut 8-32 x 1/4 Hex Keps Sink F
SC1099 2 SC 6-32 x 1/4 Mach-Thr Pan Phi
SP1084 1 Spcr Fibre ID 0.128” OD 0.245”
SP1086 1 Clamp Insulator Snowball
XX1280 1 Power Cord 12Ft 16AWG
XX1282 1 Strain Relief Black
XX1290 1 Knob, Bass Gain
RE1019 1 Relay, 12A, 48VDC K2
CO1345 1 Connector Binding Post Pair
Electrical Parts List (120v)
Part# Qty Description Ref Designation
