Overture 1
21
Resistors
RS2283 1 RES M/O F/P 5.1K ohm 5% 5W T/R R23
RS1036 1 RES M/F 36 ohm 5% 1/4W T/R R74
RS1058 1 RES M/F 51.1K ohm 1% 1/4W T/R R63
RS1063 1 RES M/F 1M ohm 1% 1/4W T/R R39
RS1150 1 RES M/F 43.2K ohm 1% 1/4W T/R R56
RS1153 1 RES M/F 47.5K ohm 1% 1/4W T/R R29
RS1161 1 RES M/F 11k ohm 1% 1/4W T/R R21
RS1268 1 RES M/F 2.21K ohm 1% 1/4W T/R R66
RS1342 1 RES M/F 9.09K ohm 1% 1/4W T/R R52
RS1351 1 RES M/F 13K ohm 1% 1/4W T/R R48
RS1353 3 RES M/F 3.01K ohm 1% 1/4W T/R R50-51, 57
RS1357 1 RES M/F 100 ohm 1% 1/4W T/R R54
RS1370 1 RES M/F 3.57K ohm 1% 1/4W T/R R24
RS1455 3 RES M/F 150K ohm 1% 1/4W T/R R35-36, 49
RS1492 1 RES M/F 221K ohm 1% 1/4W T/R R30
RS1505 1 RES M/F 475K ohm 1% 1/4W T/R R37
RS1562 1 RES M/F 82.5K ohm 1% 1/4W T/R R47
RS1585 1 RES M/F 475 ohm 1% 1/4W T/R R5
RS2018 3 RES M/F 10K ohm 1% 1/4W T/R R13, 18, 26
RS2019 8 RES M/F 20K ohm 1% 1/4W T/R R2, 12, 20, 41, 58, 69-71
RS2025 2 RES M/F 9.31K ohm 1% 1/4W T/R R1, 22
RS2100 2 RES M/F 22.1K ohm 1% 1/4W T/R R9-10
RS2124 1 RES M/F 2.37K ohm 1% 1/4W T/R R6
RS2125 2 RES M/F 59K ohm 1% 1/4W T/R R7, 15
RS2127 1 RES M/F 12.4K ohm 1% 1/4W T/R R8
RS2129 1 RES M/F 5.49K ohm 1% 1/4W T/R R11
RS2132 1 RES M/F 21.5K ohm 1% 1/4W T/R R17
RS2134 1 RES M/F 324K ohm 1% 1/4W T/R R19
RS2139 1 RES M/F 200 ohm 1% 1/4W T/R R25
RS2140 1 RES M/F 619K ohm 1% 1/4W T/R R32
RS2141 1 RES M/F 110K ohm 1% 1/4W T/R R33
RS2142 3 RES M/F 100K ohm 1% 1/4W T/R R34, 38, 53
RS2143 4 RES M/F 3.32K ohm 1% 1/4W T/R R27, 40, 46, 55
RS2144 2 RES M/F 1.3K ohm 1% 1/4W T/R R42, 60
RS2146 1 RES M/F 1.5M ohm 1% 1/4W T/R R44
S2147 1 RES M/F 249K ohm 1% 1/4W T/R R45
RS2148 1 RES M/F 130K ohm 1% 1/4W T/R R59
RS2149 6 Res. Fuse 1K ohm 5% 1/4W T/R R61-62, 64, 72-73, 76
RS2150 2 Res. Fuse 0.22 ohm 5% 1/2W T/R R65, 77
RS2151 1 RES M/O F/P 1K ohm 5% 2W T/R R68
S2152 1 RES M/F 75K ohm 1% 1/4W T/R R81
S2155 2 RES M/F 33K ohm 5% 1/2W T/R R43, 43B
Electrical Parts List (120v)
Part# Qty Description Ref Designation
